1.F00VC01001 Injector Valve Assembly’s Introduction

Injector valve assembly is one of the most important running parts, it is consisted of valve rod and valve cap, installed in the controlling room in the house body of injector. The main function of injector valve assembly is to control oil injection and oil return. Injector valve assembly is one of the most core components, also one of parts with the highest damage rate.

Valve cap

When checking the valve cap, you need to use microscope to observe the contact surface between the valve cap and the ball to see whether the valve cap is damaged or not, if there is damage, the valve cap must be replaced.

Valve rod

.Check the top of valve rod which has contact with valve cap, if the valve rod has damage on the surface, its original silver color turns into white, the valve rod needs to be replaced.

.Check the valve rod’s contact part with injector, if the valve rod has damage on the surface, its original silver color turns into white, the valve rod needs to be replaced.

2.F00VC01001 Injector Valve Assembly’s Basic Information

Title	China made brand new fuel injector valve assembly F00VC01001
SKU1	G1S8F00VC01001
SKU2	G1L10F00VC01001/L10000B2BC01001
SKU3	G1F2F00VC01001/F20000B2BC01001（High quality）

3.F00VC01001 Injector Valve Assembly’s Application Information for Injectors



（1）F00VC01001 Injector Valve Assembly’s Car Model Matching Information

Injector Part Number	Car Model	OE Number	OE Number	OE Number	OE Number	OE Number	OE Number	OE Number	OE Number
0 445 110 009	MERCEDES-BENZ	611 070 04 87	A 611 070 04 87
0 445 110 010	MERCEDES-BENZ	611 070 04 87	A 611 070 04 87
0 445 110 011	MERCEDES-BENZ	611 070 05 87	A 611 070 05 87	A 611 070 05 87 38	A 611 070 04 87	611 070 05 87 38	611 070 03 87	611 070 04 87	A 611 070 03 87
0 445 110 012	MERCEDES-BENZ	611 070 05 87	A 611 070 05 87	611 070 04 87	A 611 070 04 87
0 445 110 014	MERCEDES-BENZ	668 070 02 87	668 070 06 87	A 668 070 06 87	A 668 070 01 87	668 070 01 87	A 668 070 02 87
0 445 110 015	MERCEDES-BENZ	668 070 02 87	668 070 06 87	A 668 070 06 87	A 668 070 02 87
0 445 110 024	MERCEDES-BENZ	611 070 06 87	A 611 070 06 87	A 611 070 06 87 38	611 070 06 87 38
0 445 110 025	MERCEDES-BENZ	611 070 06 87	A 611 070 06 87
0 445 110 034	MERCEDES-BENZ	613 070 01 87	A 613 070 01 87
0 445 110 035	MERCEDES-BENZ	613 070 01 87	A 613 070 01 87
0 445 110 045	MERCEDES-BENZ	628 070 01 87	A 628 070 01 87
0 445 110 046	MERCEDES-BENZ	628 070 01 87	A 628 070 01 87
0 445 110 069	MERCEDES-BENZ	611 070 08 87	A 611 070 08 87
0 445 110 070	MERCEDES-BENZ	611 070 08 87	A 611 070 08 87
0 445 110 071	MERCEDES-BENZ	611 070 09 87	A 611 070 09 87
0 445 110 072	MERCEDES-BENZ	611 070 09 87	A 611 070 09 87
0 445 110 073	MERCEDES-BENZ	628 070 02 87	A 628 070 02 87	A 628 070 01 87	628 070 01 87
0 445 110 074	MERCEDES-BENZ	628 070 02 87	A 628 070 02 87	628 070 01 87	A 628 070 01 87
0 445 110 093	MERCEDES-BENZ	628 070 03 87	A 628 070 03 87
0 445 110 094	MERCEDES-BENZ	628 070 03 87	A 628 070 03 87
F 00Z C99 027



（2）F00VC01001 Injector Valve Assembly’s Application for Injectors’ Part Number

Injector Series	Injector Part Number	System Pressure	Re-manufactured Part Number	System Pressure	Universal Number	System Pressure	Universal Number	System Pressure	Universal Number
CRI1-13	0 445 110 009		0 986 435 004	1350	0 445 110 010		0 445 110 011	1350	0 445 110 012
CRI1-13	0 445 110 010		0 986 435 004	1350	0 445 110 009		0 445 110 011		0 445 110 012
CRI1-13	0 445 110 011	1350	0 986 435 004	1350	0 445 110 012
CRI1-13	0 445 110 012		0 986 435 004	1350	0 445 110 011	1350
CRI1-13	0 445 110 014		0 986 435 005	1350	0 445 110 015
CRI1-13	0 445 110 015		0 986 435 005	1350	0 445 110 014
CRI1-13	0 445 110 024	1350	0 986 435 020	1350	0 445 110 025
CRI1-13	0 445 110 025		0 986 435 020	1350	0 445 110 024	1350
CRI1-13	0 445 110 034		0 986 435 012		0 445 110 035		0 445 110 095		0 445 110 096
			0 986 435 037		0 445 110 201	1350	0 445 110 202
			0 986 435 063
CRI1-13	0 445 110 035		0 986 435 012		0 445 110 034		0 445 110 095		0 445 110 096
			0 986 435 037		0 445 110 201	1350	0 445 110 202
			0 986 435 063
CRI1-13	0 445 110 045		0 986 435 031		0 445 110 046		0 445 110 073		0 445 110 074
			0 986 435 032
CRI1-13	0 445 110 046		0 986 435 031		0 445 110 045		0 445 110 073		0 445 110 074
			0 986 435 032
CRI1-13	0 445 110 069		0 986 435 158		0 445 110 070		0 445 110 105		0 445 110 106
			0 986 435 045		0 445 110 170		0 445 110 171
			0 986 435 164		0 445 110 181	1350	0 445 110 182
			0 986 435 053
CRI1-13	0 445 110 070		0 986 435 158		0 445 110 069		0 445 110 105		0 445 110 106
			0 986 435 045		0 445 110 170		0 445 110 171
			0 986 435 053		0 445 110 181	1350	0 445 110 182
			0 986 435 164
CRI1-13	0 445 110 071		0 986 435 041		0 445 110 072		0 445 110 099		0 445 110 100
			0 986 435 071		0 445 110 199	1350	0 445 110 200
			0 986 435 061
CRI1-13	0 445 110 072		0 986 435 041		0 445 110 071		0 445 110 199	1350	0 445 110 200
			0 986 435 071		0 445 110 099		0 445 110 100
			0 986 435 061
CRI1-13	0 445 110 073		0 986 435 031		0 445 110 074
			0 986 435 032
CRI1-13	0 445 110 074		0 986 435 031		0 445 110 073
			0 986 435 032
CRI1-13	0 445 110 093	1350	0 986 435 035	1350	0 445 110 094
CRI1-13	0 445 110 094		0 986 435 035	1350	0 445 110 093	1350



4.F00VC01001 Injector Valve Assembly’s Specifications and Dimensions Parameters

Valve Assembly Size	13 cm*2 cm *2 cm
Valve Assembly Box Size	14 cm *3 cm *3 cm
Valve Assembly Packing Size	31 cm *12 cm
Valve Assembly Net Weight	0.03kg
Valve Assembly Gross Weight	0.03kg
Valve Assembly Quality	China Made Brand New
Valve Assembly MOQ	4PCS

5.F00VC01001Valve Assembly’s spare parts list

No.	1	2
Name	Injector Valve Assembly	Valve Assembly Anti-rust Paper
Description	Valve Assembly Part Number F00VC01001	Prevent the valve assembly from rusting
No.	3	4
Name	Valve Assembly Box (Cylinder)	VCI Anti-rust Bag
Description	Protect the valve assembly from being damaged by colliding	Prevent the valve assembly from rusting
No.	5
Image		/
Name	Valve Assembly Box (Square)	/
Description	Protect the valve assembly from being damaged by colliding	/



Minors are prohibited from using the injector valve assembly, valve assembly anti-rust paper, valve assembly box, and VCI anti-rust bag to avoid personal injury.

The valve assembly box is recyclable and can be reused.

VCI anti-rust bag is non-degradable material, please dispose of it properly after use.

6.F00VC01001 Injector Valve Assembly’s Quality Control

Valve Assembly Testing

All parts of the injector valve assembly are subjected to precision testing, high temperature testing, low temperature testing, withstand pressure testing, leakage testing, durability testing, and various working conditions testing.

Injector Valve Assembly Inspection

The factory inspection of the injector valve assembly is undergone full inspection, random inspection, and batch inspection three inspections. Different brands of test benches are used to test the same injector valve assembly for a total of no less than three times for factory inspection, and the fuel injector installation testing environment are progressed in dust-free workshop.

Injector Valve Assembly Installation

When matching the valve cap and valve steam, Shumatt strictly complies with the standard of valve cap and valve stem clearance technical indicators to ensure that each valve assembly meets the factory standards and use standards.

7.F00VC01001 Injector Valve Assembly’s Warranty Instructions

Valve Assembly Warranty Conditions and Instructions

It is necessary to provide pictures, videos, or test reports detected by the injector valve assembly inspection equipment when the valve assembly is abnormal during use as evidence to feed back to the salesman.

Abnormal conditions are properly explained such as：1.Smoke, 2. Engine shake, 3. Difficulty starting the engine, 4. Engine noise, 5. oil leakage etc.

 Valve Assembly Warranty Coverage

. Within 15 days after customer receives the F00VC01001 injector valve assembly, if there is a performance failure and the product has no appearance damage, customer can choose to replace it or repair it;

. If the F00VC01001 injector valve assembly has performance problems during the warranty period (3 months), and it is confirmed that it is product’s problems after testing, you can contact our salesmen to replace the same model or a reworked product with the same performance for free;

. If the injector house has obvious scratches, it can only be repaired and it will be returned as it is if the product is confirmed to be fault-free.

Injector Valve Assembly Out of Warranty Coverage

.The warranty period has expired.

.Injector valve assembly failure caused by high temperature, high pressure, humidity, rain and snow,

saline-alkali land, earthquake, and used in abnormal environment.

.Injector valve assembly damage caused by man-made reasons (throwing, strong magnetic field magnetization, set fire).

.Injector valve assembly failure or injector damage caused by non-injector design, technology, manufacturing, quality and other issues.

.Injector valve assembly failure due to system pressure exceeding system approved pressure.

.Injector valve assembly failure caused by system voltage exceeding approved voltage.

.Injector valve assembly failure caused by impurities (water, lead, aluminum powder, iron powder, sulfide)

in the system fuel exceeding the standard requirements.

.Injector valve assembly failure caused by not installing according to the tightening torque specified in the vehicle engine maintenance manual (the tightening torque is too large or too small).

.Injector valve assembly failure caused by not following the installation angle specified in the injector maintenance manual.

.Injector valve assembly failure caused by not following the cleaning requirements specified in the injector maintenance manual.

.Injector valve assembly failure caused by failure to replace consumable parts as specified in the injector maintenance manual.

8.F00VC01001 Valve Assembly Purchase Payment Terms

Payment Terms： T/T, PayPal, Alipay, WeChat

Please contact our salesmen for specific payment information.

9.F00VC01001 Valve Assembly’s Shipping Ways

Destination in China areas: SF Express, Debon Express, the corresponding logistics company can be provided according to customer requirements in special cases.

Destinations out of China’s areas：DHL, UPS, FedEx, TNT air, ocean or other shipping methods required by customers.

10.F00VC01001 Valve Assembly’s Lead Time

Lead time：Send out within 3 – 7 working days after receiving payment（Except for special products and special cases）.
